Zeutschel OS 15000
| TECHNICAL SPECIFICATIONS | |
| Compatible film types | Microfiche; jackets; jumbo fiche; ultrafiche; microcards; 16/35 mm roll microfilm; cartridge (M-type, C-clip); aperture cards; photographic slides; negatives; 35 mm perforated films |
| Image sensor | 10 MP high-resolution area array with real-time on-screen view |
| Lens Optics | Production-level, high-end customized lens developed specifically for microform clarity |
| Capture mode | Grayscale or bi-tonal |
| Capture time | 1/3 second per image |
| Reduction ratio | 7x to 60x continuously |
| Scan area | max. 35 mm x 47 mm / 1.38 x 1.85 inches (on film) |
| Output resolution | 100 – 600 dpi |
| Weight | 7.2 kg / 16 lbs |
| Light source | Custom-calibrated, color-compatible LED array |
| Interface | USB 3.0 |
| Dimensions | (w x d x h) 450 mm x 515 mm x 230 mm 17.7 x 20,3 x 9,1 inches |
Download detailed specification:
